FESTO – GRLA-1/8-QS-6-D

$23.85

- +
The Festo GRLA-1/8-QS-6-D one-way flow control valve regulates exhaust airflow for precise pneumatic cylinder speed control. Featuring a G1/8 threaded connection, a 6 mm QS push-in fitting and slotted screw adjustment, it operates at pressures from 0.2 to 10 bar.
  • Adjustable cylinder speed: Regulates exhaust airflow for controlled pneumatic cylinder movement.
  • One-way flow control: Meters airflow in one direction while allowing free flow in the opposite direction.
  • Fine airflow adjustment: Slotted adjustment screw allows precise setting to suit the application.
  • 6 mm push-in connection: QS fitting accepts pneumatic tubing with a 6 mm outside diameter.
  • G1/8 threaded connection: Screws directly into compatible pneumatic ports.
  • Flexible installation: Can be mounted in any orientation.
  • Operating pressure: Suitable for pressures from 0.2 to 10 bar.
  • Temperature range: Operates from −10°C to +60°C.
Specification Details
Brand Festo
Model GRLA-1/8-QS-6-D
Part number 193144
Product type One-way flow control valve
Valve function Exhaust air flow control
Tubing connection QS push-in, 6 mm outside diameter
Threaded connection G1/8
Adjustment Slotted head screw
Mounting type Threaded
Mounting position Any
Operating pressure 0.2–10 bar
Standard nominal flow rate, flow control direction 185 L/min
Standard nominal flow rate, non-return direction 160–240 L/min
Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
Ambient temperature −10°C to +60°C
Medium temperature −10°C to +60°C
Nominal tightening torque 3 Nm ±10%
Weight 22 g
Threaded plug material Wrought aluminium alloy
Swivel fitting material Chrome-plated die-cast zinc
Adjustment screw material Brass
Seal material NBR
Release ring material POM
Materials compliance RoHS compliant
