FESTO – QSL-12 (10)

$152.50

- +
The FESTO QSL-12 push-in L-connector joins two 12 mm tubes at a 90° angle for convenient pneumatic line routing. Featuring a lightweight PBT housing, NBR seals and blue release rings, it allows quick tubing installation and removal.

FESTO QSL-12 Product Features

  • 90° elbow design: Joins two 12 mm outside-diameter tubes for convenient air line routing.
  • Push-in connections: Allow quick and simple tubing installation.
  • Blue release rings: Enable easy tubing removal during maintenance or system changes.
  • Compact construction: Helps route pneumatic tubing around corners and within confined spaces.
  • Lightweight PBT housing: Keeps component weight low.
  • NBR tubing seals: Provide secure sealing around connected tubing.
  • Stainless steel retaining claws: Hold tubing securely in place.
  • Flexible installation: Suitable for mounting in any position.
  • Media compatibility: Suitable for compressed air and liquid, ice-free water within specified operating limits.

FESTO QSL-12 Product Specifications

Specification Details
Manufacturer FESTO
Model QSL-12
Part number 153074
Product type Push-in L-connector
Design 90° L-shape, push-pull principle
Connection, port 1 12 mm tubing outside diameter
Connection, port 2 12 mm tubing outside diameter
Nominal size 10 mm
Operating pressure, full temperature range −0.95 to 6 bar
Temperature-dependent operating pressure −0.95 to 14 bar
Ambient temperature −10°C to +80°C
Operating medium Compressed air to ISO 8573-1:2010 [7:-:-]; liquid, ice-free water
Water operating limits Maximum 6 bar at maximum +50°C
Housing material PBT
Release ring material POM
Tubing seal material NBR
Tubing retaining claws High-alloy stainless steel
Release ring colour Blue
Tubing insertion depth 23.4 mm
Mounting position Any
Product weight 25 g
Corrosion resistance class CRC 1 — low corrosion stress
Materials compliance RoHS-compliant
Lubricated operation Permitted
Manufacturer pack size 10 pieces
