FESTO – QST-1/4-12 (10)

$255.40

- +
The FESTO QST-1/4-12 push-in T-fitting connects an R1/4 male threaded port to two 12 mm tubes for convenient pneumatic line branching. Featuring a PBT housing, nickel-plated brass threaded connection and blue release rings, it allows quick tubing installation and removal.

FESTO QST-1/4-12 Product Features

  • T-shaped design: Connects an R1/4 male threaded port to two 12 mm outside-diameter tubes.
  • Push-in connections: Allow fast, simple tubing installation.
  • Blue release rings: Make tubing removal easy during maintenance.
  • Pre-coated male thread: Provides sealing at the threaded connection.
  • Nickel-plated brass threaded component: Offers a robust connection to pneumatic equipment.
  • Lightweight PBT housing: Keeps overall component weight low.
  • NBR seals and stainless steel retaining claws: Seal and hold tubing securely.
  • Flexible mounting: Can be installed in any position.
  • Media compatibility: Suitable for compressed air and liquid, ice-free water within specified operating limits.

FESTO QST-1/4-12 Product Specifications

Specification Details
Manufacturer FESTO
Model QST-1/4-12
Part number 190669
Product type Push-in T-fitting
Design T-shape, push-pull principle
Threaded connection R1/4 male
Outlet connections 2 × 12 mm tubing outside diameter
Nominal size 8 mm
Thread sealing Pre-coated thread
Operating pressure, full temperature range −0.95 to 6 bar
Temperature-dependent operating pressure −0.95 to 14 bar
Ambient temperature −10°C to +80°C
Operating medium Compressed air to ISO 8573-1:2010 [7:-:-]; liquid, ice-free water
Water operating limits Maximum 6 bar at maximum +50°C
Housing material PBT
Threaded component material Nickel-plated brass
Release ring material POM
Tubing seal material NBR
Tubing retaining claws High-alloy stainless steel
Release ring colour Blue
Tubing insertion depth 23.4 mm
Installation tool size 14 mm external hexagon
Mounting position Any
Product weight 38 g
Corrosion resistance class CRC 1 — low corrosion stress
Materials compliance RoHS-compliant
Lubricated operation Permitted
